Create your own pin badges

How to create button badges using Paint Tool SAI

Create your own pin badges

This tutorial contains everything you need to know about creating your 25mm (1 inch) custom badges using Paint Tool SAI.

1. Download our template

Templates are available for Photoshop, Illustrator and Paint Tool SAI.

Click >> here << to download our badge templates.

Important - Colour Management for Paint Tool SAI
Please note that Paint Tool SAI can only create documents in RGB colour whereas we only print in CMYK colour.

A quick search on the internet for 'the difference between RGB and CMYK' will provide you with a wealth of information on this subject, but we wanted to make you aware that the colours of your designs on screen will be different to the colours of your final printed products.

The image below shows the RGB palette on the left and the same palette converted to CMYK on the right. RGB colours appear vivid with bright blues and greens. CMYK in comparison appear flatter with slightly duller colours.

We convert all Paint Tool SAI images from RGB to CMYK before printing so do remember to bear these colour differences in mind. Always remember to order samples if you require any colour accuracy or if youare unsure or feel that you may be unhappy with the results.

2. Understanding our layers

Please do not rename existing layers or create additional layers as this will confuse our systems when processing your designs.

‘Instructions’ Layer
This layer contains our logo and all of the instructions you will need to complete your Pin Badges. This layer is locked and should not be used.

'Artwork’ Layer
This layer is where you should place your artwork.

'Cut Line’ Layer
This layer tells you where we will cut your badge.

'Guidelines’ Layer
This layer tells you which areas are ‘safe’ areas.

3. Importing your Design

Select the 'Artwork' layer in your layers palette and either draw your design directly into this layer or, simply copy and paste previously saved artwork.

Please ensure that all artwork extends to the edge of the red dotted line.

All artwork between the green line and the red dotted line will not be visible. All artwork between the green line and the blue line will be on the edge of the badge. Anything inside of the blue circle is what will be on the front of the badge. This is the safe area so please place all important artwork INSIDE the blue circle.

Please make sure that all fonts are embedded before saving. To do this in Photoshop, select the text layer, right click and select ‘Rasterize layer’. In Illustrator, select the text elements and choose the ‘Type’ from the main menu bar along the top and choose ‘Create Outlines’

Once you’ve imported your design into the template - voila! You’re done... It’s as easy as that.

4. Submission checklist

Congratulations, you've finished creating your Pin badges! All you have to do now is check the following before submission...

  • You have imported your artwork onto the ‘Artwork’ layer
  • You have not edited or deleted any of the other layers
  • Your artwork extends to the edge of the red dotted line
  • Any important artwork is INSIDE the blue circle
  • All fonts and images are embedded
  • Your template contains 1 Pin badge design only. Any other designs are on a separate document.

5. Saving and submitting your designs

There are 3 different ways to save and submit your designs...

1. Submit your artwork immediately

If you have already created your designs, you can send them to us using the 'Upload Artwork' button, located on our product pages or by emailing them to ‘’.

Save all Paint Tool SAI files in .Psd format. Here’s how…

Name each of your designs appropriately so that we know which designs you are referring to. Your file names should include 1. your name, 2. design number, 3. chosen product and 4. the date that you placed your order through our website. Here’s an example…

Select all of the designs that you would like to submit, right click and choose SEND TO > COMPRESSED (ZIPPED) FOLDER.

This will create a compressed folder containing all of your designs. Rename this folder so that it contains your name and the date that you placed your order on our website. Like this…

Please add all of your designs into one folder. So, if you purchased charms, stickers and pins, for example, just pop them all in the same, compressed folder and pass it our way.

2. Submit your artwork later

If you have placed your order via our website but your designs aren’t quite ready yet, that’s ok. You have up to 2 weeks to submit your artwork to us, which allows you to take advantage of any special offers that we’re running.

To submit your designs later, save them with 1. your name, 2. design number, 3. chosen product and 4. your order number. Then email them to ‘’.

Save all Paint Tool SAI files in .Psd format. Here’s how…

3. Placing a re-order

If you have placed an order in the past and would like to re-order those designs that’s great! We store your artwork for a maximum of 6 months, which saves you the hassle of having to resubmit your designs via email.

To place a re-order, simply place your order online, email us with your previous order number(s) and let us know that you are placing a re-order.

You may only want to order 1 or 2 designs from your previous order(s). To do this simply quote your old file name(s) and let us know how you would like them to be produced and in what quantities.

Here’s how to do it…

Hi Zap!,

I’ve just placed an order #12345 on your website and would like to re-order the following designs from a previous order #12121. Please can I have…




If you have any questions about this tutorial or any other aspects of our website and manufacturing processes, please do not hesitate to get in touch. We’d love to hear from you.
